8-port 10/100Mbps with 4-port PoE Switch PLANET FSD-804P

Model

FSD-804P

Description

8-Port 10/100Mbps with 4-Port PoE Ethernet Switch

Network Connector

8-Port RJ-45 for 10/100TX

4-Port with PoE injector function (Port 1 ~ Port 4)

LED indicators

One power

Three for port 1-4; PoE in-use, LNK/ACT, 100

Two for port 5-8; LNK/ACT, 100

Switch architecture

Store and forward switch architecture Back-plan up to 1.6Gbps

MAC address

2K MAC address table with Auto learning function

Remote power feeding

End-point insert type and compatible with IEEE802.3af

Per port feeding power: 15.4Watts (maximum)

Power Supply

90~240VAC, 50/60Hz,

45 watts power consumption maximum

Operating environment

0~40 degree C, 10%~95%RH

Storage environment

-40~70 degree C, 95% RH

Dimension

217mm (W) x 135mm (D) x 43mm (H)

1U height, 10-inch/19-inch rack-mountable

EMI

FCC Class B, CE

Standard Compliance

IEEE802.3 Ethernet

IEEE802.3u Fast Ethernet

IEEE802.3x Flow Control

IEEE802.3af Power over Ethernet
