Hardware Specifications |
|
|
10/100/1000BASE-T Ports |
16 auto MDI/MDIX RJ45 ports |
|
LED Display |
One for Power, one for Link/Act per port |
|
Enclosure |
Metal |
|
Dimensions (W x D x H) |
155 x 118 x 46 mm |
|
Weight (g) |
538g |
|
Power Requirements(External power adapter) |
12VDC, 1A |
|
Power Consumption |
10 watts/34 BTU |
|
Switch Specifications |
|
|
Switch Processing Scheme |
Store-and-Forward |
|
Address Table |
8K |
|
Flow Control |
Back pressure half duplex |
|
IEEE 802.3x pause frame full duplex |
|
|
Switch Fabric |
32Gbps |
|
Throughput(packet per second) |
23.8Mpps@64 bytes |
|
Jumbo packet size |
9K |
|
Standards Conformance |
|
|
Standards Compliance |
IEEE 802.3 (Ethernet) |
|
IEEE 802.3u (Fast Ethernet) |
|
|
IEEE 802.3ab (Gigabit Ethernet) |
|
|
IEEE 802.3x (Full-duplex Flow Control) |
|
|
IEEE 802.3az Energy Efficient Ethernet (EEE) |
|
|
Regulatory Compliance |
FCC Part 15 Class B, CE |
|
Environments |
|
|
Temperature |
Operating: 0~50 degrees C |
|
Storage: -10~70 degrees C |
|
|
Humidity |
Operating: 5~95% |
|
Storage: 5~95% (non-condensing) |
|
