Hardware Specifications |
|
|
Copper Ports |
48 x 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports |
|
SFP/mini-GBIC Slots |
4 100/1000BASE-X SFP interfaces, supporting 100/1000Mbps dual mode |
|
Console |
1 x RS232 to RJ45 serial port (115200, 8, N, 1) |
|
Reset Button |
System factory default |
|
Switch Architecture |
Store-and-Forward |
|
Switch Fabric |
52Gbps / non-blocking |
|
Switch Throughput @ 64 bytes |
38.6Mpps @ 64 bytes |
|
MAC Address Table |
8K entries |
|
Shared Data Buffer |
4.1 megabits |
|
Flow Control |
IEEE 802.3x pause frame for full-duplex |
|
Back pressure for half-duplex |
|
|
Jumbo Frame |
9216 bytes |
|
Reset Button |
> 5 sec: Factory default |
|
LED |
System: |
|
Power (Green) |
|
|
10/100/1000T RJ45 Interfaces (Port 1 to Port 24): |
|
|
1000 LNK / ACT (Green), 10/100 LNK/ACT (Orange) |
|
|
100/1000Mbps SFP Interfaces (Port 25 to Port 26): |
|
|
1000 LNK / ACT (Green), 100 LNK/ACT (Orange) |
|
|
Power Requirements |
100~240V AC, 50/60Hz, 0.8A (max.) |
|
Power Consumption / Dissipation |
Max. 14 watts / 47 BTU |
|
Dimensions |
445 x 207 x 45 mm (1U height) |
|
Weight |
2.1kg |
|
ESD Protection |
Yes |
|
Enclosure |
Metal |
|
Port Mirroring |
TX / RX / Both |
|
Many-to-1 monitor |
|
|
VLAN |
802.1Q tagged-based VLAN |
|
Up to 256 VLAN groups, out of 4094 VLAN IDs |
|
|
802.1ad Q-in-Q tunneling (VLAN stacking) |
|
|
Voice VLAN |
|
|
Protocol VLAN |
|
|
Private VLAN (Protected port) |
|
|
GVRP |
|
|
Management VLAN |
|
|
Link Aggregation |
IEEE 802.3ad LACP and static trunk |
|
Supports 8 groups of 8-port trunk |
|
|
Spanning Tree Protocol |
STP, IEEE 802.1D Spanning Tree Protocol |
|
RSTP, IEEE 802.1w Rapid Spanning Tree Protocol |
|
|
MSTP, IEEE 802.1s Multiple Spanning Tree Protocol |
|
|
STP BPDU Guard, BPDU Filtering and BPDU Forwarding |
|
|
IGMP Snooping |
IPv4 IGMP (v2 / v3) Snooping |
|
IGMP Querier |
|
|
Up to 256 multicast groups |
|
