Hardware Specifications |
|
|
10/100/1000BASE-T Copper Ports |
24 auto-MDI/MDI-X ports |
|
802.3af/802.3at PoE Injector Ports |
24 |
|
1000BASE-X SFP/mini-GBIC Slots |
2 |
|
Switch Architecture |
Store-and-Forward |
|
Switch Fabric |
52Gbps/non-blocking |
|
Switch Throughput@64 bytes |
38.6Mpps@64 bytes |
|
MAC Address Table |
8K entries |
|
Jumbo Frame |
9216 bytes |
|
Flow Control |
IEEE 802.3x pause frame for full-duplex; back pressure for half-duplex |
|
LED |
System: Power (Green) |
|
10/100/1000T RJ45 Interfaces |
|
|
1000 LNK / ACT (Green), 10/100 LNK/ACT (Orange), PoE (Orange) |
|
|
1000Mbps SFP Interfaces |
|
|
1000 LNK / ACT (Green) |
|
|
Dimensions (W x D x H) |
445 x 207 x 45 mm (1U height) |
|
Enclosure |
Metal |
|
Weight |
2.85kg |
|
Power Requirements |
100~240V AC, 50/60Hz, 4A (max.) |
|
Thermal Fan |
2 |
|
Power over Ethernet |
|
|
PoE Standard |
IEEE 802.3af Power over Ethernet/PSE |
|
IEEE 802.3at Power over Ethernet Plus/PSE |
|
|
PoE Power Output |
Per port 52V DC, 300mA. max. 15.4 watts (IEEE 802.3af) |
|
Per port 52V DC, 600mA. max. 30 watts (IEEE 802.3at) |
|
|
PoE Power Budget |
220 watts |
|
Number of PDs, 7 watts |
24 |
|
Number of PDs, 15.4 watts |
14 |
|
Number of PDs, 30 watts |
7 |
|
Standards Conformance |
|
|
Regulatory Compliance |
FCC Part 15 Class A, CE |
|
Standards Compliance |
IEEE 802.3 10BASE-T |
|
IEEE 802.3u 100BASE-TX |
|
|
IEEE 802.3ab Gigabit 1000BASE-T |
|
|
IEEE 802.3z Gigabit SX/LX |
|
|
IEEE 802.3x flow control and back pressure |
|
|
IEEE 802.3af Power over Ethernet |
|
|
IEEE 802.3at High Power over Ethernet |
|
