Hardware Specification |
|
|
Network Connector |
8-Port RJ-45 for 10/100Base-TX |
|
Switch Throughput |
1.19Mpps |
|
Switch Fabric |
1.6Gbps |
|
MAC Address |
1K MAC address table with Auto learning function |
|
Shared Buffer |
768K |
|
Power Requirement |
9V DC, 700mA |
|
Operating Environment |
0~50 Degree C, 5%~95% RH |
|
Storage Environment |
-20~70 Degree C, 5%~95% RH |
|
Dimension (W x D x H) |
184 × 110 × 30 mm |
|
Switch Specification |
|
|
Switch Architecture |
Store-and-Forward |
|
Flow Control |
IEEE 802.3x full duplex operating and flow control |
|
Standard Compliance |
|
|
Network Standard |
IEEE 802.3 10Base-T |
|
IEEE 802.3u 100Base-TX |
|
|
IEEE 802.3x Flow Control and Back pressure |
|
|
EMI |
FCC Class B, CE |
