Hardware Specifications |
|
|
10/100Mbps Copper Ports |
16 10/100Base-TX RJ-45 Auto-MDI/MDI-X ports |
|
Gigabit Copper Ports |
2 10/100/1000Base-T RJ-45 Auto-MDI/MDI-X ports |
|
SFP/mini-GBIC Slots |
2 1000Base-X SFP interfaces, shared with Port-17 to Port-18 |
|
Switch Architecture |
Store-and-Forward |
|
Switch Fabric |
7.2Gbps / non-blocking |
|
Throughput |
5.35Mpps@64Bytes |
|
Address Table |
4K entries, automatic source address learning and ageing |
|
Share Data Buffer |
2.75Mb embedded memory for packet buffers |
|
Flow Control |
IEEE 802.3x pause frame for full-duplex |
|
Back pressure for half-duplex |
|
|
Maximum Transmit Unit size (MTU size) |
1536 Bytes |
|
Reset Button |
< 5 sec: System reboot |
|
> 5 sec: Factory Default |
|
|
Dimensions |
440 x 200 x 44.5 mm, 1U height |
|
Weight |
2.55kg |
|
LED |
System: |
|
Power (Green) |
|
|
10/100Base-TX RJ45 Interfaces (Port1 to Port16) |
|
|
10/100Mbps LNK/ACT (Green) |
|
|
PoE In-Use (Orange) |
|
|
10/100/1000Base-T RJ45 / SFP Interfaces (Port17 to Port18): |
|
|
LNK/ACT (Green) |
|
|
100/1000 (Green) |
|
|
PoE Usage: 50W, 100W, 150W, 190W (Orange) |
|
|
Cable Twisted-Pair |
10Base-T: 2-Pair UTP CAT. 3, 4, 5, up to 100 meters |
|
100Base-TX: 2-Pair UTP CAT. 5, 5e up to 100 meters |
|
|
1000Base-T: 4-Pair UTP CAT. 5e, 6 up to 100 meters |
|
|
Cable Fiber-Optic Cable |
1000Base-SX: |
|
50/125μm or 62.5/125μm multi-mode fiber optic cable, up to 550m |
|
|
(varying on SFP module) |
|
|
1000Base-LX : |
|
|
9/125μm single-mode fiber optic cable, up to 10/20/30/40/50/70/120 |
|
|
kilometers (varying on SFP module) |
|
|
Power Requirements |
100~240VAC, 50/60Hz, 4A |
|
Power Consumption |
Max. 240 watts / 816 BTU |
|
ESD Protection |
2KVDC |
|
Power over Ethernet |
|
|
PoE Standard |
IEEE 802.3af / 802.3at PoE / PSE |
|
PoE Power Supply Type |
End-span |
|
PoE Power Output |
Per Port 52V DC, Max. 30.8 watts |
|
Power Pin Assignment |
1/2(+), 3/6(-) |
|
PoE Power Budget |
220 watts (max.) |
|
PoE Ability PD @ 7 watts |
16 units |
|
PoE Ability PD @ 15.4 watts |
14 units |
|
PoE Ability PD @ 30.8 watts |
7 units |
|
Layer 2 Functions |
|
|
Port Configuration |
Port disable / enable |
|
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection |
|
|
Flow Control disable / enable |
|
|
Port Status |
Display each port’s speed duplex mode, link status, flow control status, auto negotiation status and trunk status |
|
Port Mirroring |
TX / RX / Both |
|
Many-to-1 monitor |
|
|
VLAN |
802.1Q tagged-based VLAN, up to 32 VLAN groups, out of 4094 VLAN IDs |
|
Port-based VLAN, up to 18 VLAN groups |
|
|
MTU VLAN |
|
|
Link Aggregation |
2 groups of 4-Port 10/100Base-TX trunk supported |
|
1 group of 2-Port 10/100/1000Base-T trunk supported |
|
|
QoS |
Allow to assign low / high priority on each port |
|
First-In-First-Out, All-High-before-Low, Weight-Round-Robin QoS policy |
|
|
IGMP Snooping |
IGMP (v1/v2) Snooping, up to 32 multicast groups |
|
Security Control |
MAC address binding |
|
TCP & UDP filter |
|
|
Management Functions |
|
|
Basic Management Interfaces |
Web Browser, SNMP v1 |
|
Standards Conformance |
|
|
Regulation Compliance |
FCC Part 15 Class A, CE |
|
Standards Compliance |
IEEE 802.3 Ethernet |
|
IEEE 802.3u Fast Ethernet |
|
|
IEEE 802.3ab Gigabit Ethernet |
|
|
IEEE 802.3z Gigabit Ethernet |
|
|
IEEE 802.3x Full-duplex flow control |
|
|
IEEE 802.1Q VLAN |
|
|
IEEE 802.1p QoS |
|
|
IEEE 802.1D Spanning Tree Protocol |
|
|
IEEE 802.1w Rapid Spanning Tree Protocol |
|
|
IEEE 802.3af Power over Ethernet |
|
|
IEEE 802.3at Power over Ethernet Plus |
|
