Hardware Specification |
|
|
Hardware Version |
6 |
|
10/100/1000Base-T Ports |
8 auto MDI/MDIX ports |
|
LED Display |
One for Power, Two for 1000 & Link / Act per port |
|
Switch Specification |
|
|
Switch Processing Scheme |
Store-and-Forward |
|
Address Table |
8K entries |
|
Flow Control |
Back pressure half duplex |
|
IEEE 802.3x pause frame full duplex |
|
|
Switch fabric |
16Gbps |
|
Throughput (packet per second) |
11.9Mpps |
|
Jumbo packet size |
9K |
|
Standards Conformance |
|
|
Standards Compliance |
IEEE 802.3 (Ethernet) |
|
IEEE 802.3u (Fast Ethernet) |
|
|
IEEE 802.3ab (Gigabit Ethernet) |
|
|
IEEE 802.3x (Full-duplex Flow Control) |
|
|
IEEE 802.3az Energy Efficient Ethernet (EEE) |
|
|
Regulation Compliance |
FCC Part 15 Class B, CE |
|
Power Requirements (External power adapter) |
5VDC, 1A |
|
Power Consumption (100M Full Operation) |
4.9 watts / 16 BTU |
|
Enclosure |
Metal |
|
Dimensions |
155 x 86 x 26 mm |
|
Weight |
348g |
