Copper Ports |
4 port 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports, shared with Port-1 to Port-4 |
|
SFP/mini-GBIC Slots |
48 100/1000BASE-X SFP interfaces |
|
Compatible with 100BASE-FX SFP transceiver |
|
|
Console |
1 x RS232-to-RJ45 serial port (115200, 8, N, 1) |
|
Switch Architecture |
Store-and-Forward |
|
Switch Fabric |
96Gbps |
|
Throughput |
71. 2Mpps@64Bytes |
|
Address Table |
16K entries, automatic source address learning and ageing |
|
Shared Data Buffer |
16M bits |
|
Flow Control |
IEEE 802.3x pause frame for full-duplex |
|
Back pressure for half-duplex |
|
|
Jumbo Frame |
10K bytes |
|
Reset Button |
< 5 sec: System reboot |
|
> 5 sec: Factory default |
|
|
Dimensions |
440 x 300 x 44.5 mm, 1U height |
|
Weight |
3765g |
|
LED |
System: |
|
PWR (Green), SYS (Green), Fan 1 (Red), Fan 2 (Red) |
|
|
10/100/1000T RJ45 Combo Interfaces (Port 1 to Port 4): |
|
|
1000Mbps LNK/ACT (Green) |
|
|
100Mbps LNK/ACT (Orange) |
|
|
10Mbps LNK/ACT (OFF) |
|
|
100/1000Mbps SFP Interfaces (Port 1 to Port 48) |
|
|
1000Mbps LNK/ACT (Green) |
|
|
100Mbps LNK/ACT (Orange) |
|
|
Power Requirements |
100~240VAC, 50/60Hz |
|
Power Consumption |
45 watts / 153 BTU/hr (max.) |
|
ESD Protection |
2KVDC |
|
Layer 2 Management Functions |
|
|
Port Configuration |
Port disable / enable |
|
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection |
|
|
Flow control disable / enable |
|
|
Port Status |
Display each port’s speed duplex mode, link status, flow control status, auto-negotiation status, trunk status |
|
Port Mirroring |
TX / RX / Both |
|
Many-to-1 monitor |
|
|
VLAN |
802.1Q tagged based VLAN |
|
Q-in-Q tunneling |
|
|
Private VLAN Edge (PVE) |
|
|
MAC-based VLAN |
|
|
Protocol-based VLAN |
|
|
Voice VLAN |
|
|
IP Subnet-based VLAN |
|
|
MVR (Multicast VLAN Registration) |
|
|
Up to 255 VLAN groups, out of 4095 VLAN IDs |
|
|
Link Aggregation |
IEEE 802.3ad LACP/ static trunk |
|
24 groups of 8-Port trunk supported |
|
|
Spanning Tree Protocol |
STP, IEEE 802.1D Spanning Tree Protocol |
|
RSTP, IEEE 802.1w Rapid Spanning Tree Protocol |
|
|
MSTP, IEEE 802.1s Multiple Spanning Tree Protocol |
|
|
QoS |
Traffic classification based, Strict priority and WRR |
|
8-level priority for switching: |
|
|
– Port Number |
|
|
– 802.1p priority |
|
|
– 802.1Q VLAN tag |
|
|
– DSCP/ToS field in IP packet |
|
|
IGMP Snooping |
IGMP (v1/ v2/ v3) Snooping, up to 255 multicast groups |
|
IGMP Querier mode support |
|
|
MLD Snooping |
MLD (v1/ v2) Snooping, up to 255 multicast groups |
|
MLD Querier mode support |
|
|
Access Control List |
IP-based ACL / MAC-based ACL |
|
Up to 256 entries |
|
|
Bandwidth Control |
Per port bandwidth control |
|
Ingress: 100Kbps~1000Mbps |
|
|
Egress: 100Kbps~1000Mbps |
|
|
Layer 3 Functions |
|
|
IP Interfaces |
Max. 128 VLAN interfaces |
|
Routing Table |
Max. 32 routing entries |
|
Routing Protocols |
IPv4 hardware static routing |
|
IPv6 hardware static routing |
|
|
Management |
|
|
Basic Management Interfaces |
Console / Telnet / Web browser / SNMP v1, v2c |
|
Secure Management Interfaces |
SSH, SSL, SNMP v3 |
|
SNMP MIBs |
RFC 1213 MIB-II |
|
RFC 1493 Bridge MIB |
|
|
RFC 1643 Ethernet MIB |
|
|
RFC 2863 Interface MIB |
|
|
RFC 2665 Ether-Like MIB |
|
|
RFC 2819 RMON MIB (Group 1, 2, 3 and 9) |
|
|
RFC 2737 Entity MIB |
|
|
RFC 2618 RADIUS Client MIB |
|
|
RFC 2863 IF-MIB |
|
|
RFC 2933 IGMP-STD-MIB |
|
|
RFC 3411 SNMP-Frameworks-MIB |
|
|
RFC 4292 IP Forward MIB |
|
|
RFC 4293 IP MIB |
|
|
RFC 4836 MAU-MIB |
|
|
IEEE 802.1X PAE |
|
|
LLDP |
|
|
Standards Conformance |
|
|
Regulation Compliance |
FCC Part 15 Class A, CE |
|
Standards Compliance |
IEEE 802.3 10BASE-T |
|
IEEE 802.3u 100BASE-TX/100BASE-FX |
|
|
IEEE 802.3z Gigabit SX/LX |
|
|
IEEE 802.3ab Gigabit 1000T |
|
|
IEEE 802.3x flow control and back pressure |
|
|
IEEE 802.3ad port trunk with LACP |
|
|
IEEE 802.1D Spanning Tree protocol |
|
|
IEEE 802.1w Rapid Spanning Tree protocol |
|
|
IEEE 802.1s Multiple Spanning Tree protocol |
|
|
IEEE 802.1p Class of service |
|
|
IEEE 802.1Q VLAN tagging |
|
|
IEEE 802.1X Port Authentication Network Control |
|
|
IEEE 802.1ab LLDP |
|
|
RFC 768 UDP |
|
|
RFC 793 TFTP |
|
|
RFC 791 IP |
|
|
RFC 792 ICMP |
|
|
RFC 2068 HTTP |
|
|
RFC 1112 IGMP version 1 |
|
|
RFC 2236 IGMP version 2 |
|
|
RFC 3376 IGMP version 3 |
|
|
RFC 2710 MLD version 1 |
|
|
FRC 3810 MLD version 2 |
|
