Copper Ports |
48 x 10/100/1000BASE-T RJ45 auto-MDI/MDI-X port |
|
SFP/mini-GBIC Slots |
4 10GBASE-SR/LR SFP+ interface (XE1 to XE4) |
|
Compatible with 1000BASE-SX/LX/BX SFP transceiver |
|
|
Switch Architecture |
Store-and-Forward |
|
Switch Fabric |
176Gbps/non-blocking |
|
Switch Throughput@64Bytes |
130.95Mpps |
|
Address Table |
16K entries |
|
Shared Data Buffer |
1.5Mbytes |
|
Flow Control |
IEEE 802.3x pause frame for full-duplex |
|
Back pressure for half-duplex |
|
|
Jumbo Frame |
13K bytes |
|
Reset Button |
< 5 sec: System reboot |
|
> 5 sec: Factory default |
|
|
LED |
PWR, SYS, 10/100, 1000, 10G |
|
Power Requirements |
100~240V AC, 50/60Hz, auto-sensing |
|
Dimensions |
440 x 270 x 44 mm, 1U height |
|
ESD Protection |
Contact Discharge 4KV DC |
|
Air Discharge 8KV DC |
|
|
Enclosure |
Metal |
|
Weight |
3969g |
|
Power Consumption/ Dissipation |
45 watts (max.)/154 BTU |
|
Layer 2 Functions |
|
|
Port Mirroring |
TX/RX/both |
|
Many-to-1 monitor |
|
|
VLAN |
802.1Q tagged-based VLAN |
|
Up to 4000 VLAN groups, out of 4094 VLAN IDs |
|
|
IP subnet-based VLAN |
|
|
MAC-based VLAN |
|
|
Protocol-based VLAN |
|
|
Private VLAN |
|
|
Link Aggregation |
IEEE 802.3ad LACP and static trunk |
|
Supports 32 groups with 8 ports per trunk group |
|
|
Spanning Tree Protocol |
IEEE 802.1D Spanning Tree Protocol (STP) |
|
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) |
|
|
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) |
|
|
IGMP Snooping |
IGMP snooping v1, v2, v3, up to 255 multicast groups |
|
IGMP querier mode support |
|
|
Security |
DHCP snooping |
|
Static MAC address |
|
|
MAC binding |
|
|
MAC auto binding |
|
|
Per port MAC address entries limitation |
|
|
Broadcast, multicast, unknown unicast storm control |
|
|
Management Functions |
|
|
Basic Management Interfaces |
Web browser, Telnet, console |
|
SNMP v1, v2c |
|
|
Firmware upgrade by HTTP protocol through Ethernet network |
|
|
System log |
|
|
SNMP MIBs |
RFC 1213 MIB-II |
|
RFC 1215 Generic Traps |
|
|
Standards Conformance |
|
|
Regulatory Compliance |
FCC Part 15 Class A, CE, LVD |
|
Standards Compliance |
IEEE 802.3 10BASE-T |
|
IEEE 802.3u 100BASE-TX/100BASE-FX |
|
|
IEEE 802.3z Gigabit SX/LX |
|
|
IEEE 802.3ab Gigabit 1000T |
|
|
IEEE 802.3ae 10 Gigabit Ethernet |
|
|
IEEE 802.3x flow control and back pressure |
|
|
IEEE 802.3ad port trunk with LACP |
|
|
IEEE 802.1ab LLDP |
|
|
IEEE 802.1D Spanning Tree Protocol |
|
|
IEEE 802.1w Rapid Spanning Tree Protocol |
|
|
IEEE 802.1s Multiple Spanning Tree Protocol |
|
|
IEEE 802.1Q VLAN tagging |
|
|
RFC 768 UDP |
|
|
RFC 791 IP |
|
|
RFC 792 ICMP |
|
|
RFC 2068 HTTP |
|
|
RFC 1112 IGMP v1 |
|
|
RFC 2236 IGMP v2 |
|
|
RFC 3376 IGMP v3 |
|
