| Model |
RPT-1025 |
RPT-1500 |
RPT-2000 |
|
| Capacity |
1025VA/615W |
1500VA/900W |
2000VA/1200W |
|
| INPUT | Voltage |
100V / 110V / 120V ±25% |
||
| Frequency |
50Hz / 60Hz ±10% auto sensing |
|||
| OUTPUT | Voltage (battery) |
100V / 110V / 120V ±5% |
||
| AVR |
When input voltage between -9% to -25% of nominal, increase output by 15%. |
|||
| Frequency |
50Hz / 60Hz ±1% |
|||
| Waveform |
Simulated sine wave |
|||
| Outlet quantity |
IEC*6 as standard; Customized receptacle can be discussed. |
|||
| Transfer time |
2 to 4 millisecond including detection time (typical) |
|||
| PROTECTION | Overload |
UPS automatic power off if overload exceeds 110% of nominal at 60 seconds; 130% at 3 seconds |
||
| Surge |
Yes |
|||
| Short circuit |
UPS output cut off immediately or protected by input breaker |
|||
| Tele-communication |
RJ 45 |
|||
| Fuse |
Yes |
|||
| Alarm |
Buzzer beeps under backup mode, battery low, battery charging fault, and overload |
|||
| BATTERY | Type |
12V 7Ah x2 |
12V 7.2Ah x2 |
12V 9Ah x2 |
| Typical recharge time |
4 hours to 90% |
|||
| GENERAL | Dimension(D x W x H) |
360x146x164 mm |
||
| Display |
LED or LCD indicator (Option) |
|||
| Communication interface |
USB B-type |
|||
| Audible noise |
< 40dBA (1M from surface) |
|||
| Ambient operation |
0 to 40℃ |
|||
