UPS Powercom VGS-6000

MODEL

VGS-6000

CAPACITY

6000VA

5400W

INPUT

Voltage

220V / 230V / 240V
120V to 139V under 25% load, 140V to 159V under 50% load, 160V to 179V under 75% load, 180V to 276V with 100% load

Frequency

50Hz / 60Hz ±2.5Hz auto sensing (45Hz to 65Hz user selectable)

Phase

Single phase

Power factor

> 0.97

OUTPUT

Voltage

220V / 230V / 240V ±2% (selectable output voltage)

Frequency

50Hz / 60Hz ±0.25Hz

Waveform

Pure sine wave

Phase

Single phase

Harmonic distortion

< 3% of T.H.D. at linear load

Efficiency

Approximately 89%

Connections

*Please refer below “Receptacle Options”. Customized receptacle can be discussed.

PROTECTION

Overload protection

UPS automatic power off if overload exceeds 106% to 120% of nominal at 30 seconds; 121% to 150% for 10 seconds

Short circuit protection

UPS output cut off immediately or protected by input fuse or circuit breaker

Tele-communication

RJ45

Alarm

Buzzer beeps under backup mode, battery low,  battery charging fault, and overload

BATTERY

Type

Sealed, maintenance-free lead acid battery

Typical recharge time

4 hours to 90%

Battery quantity

12V 7Ah x20

Backup time (100% load)

4 to 5 minutes

Protection

Battery low cut-off without draining any current

GENERAL

Dimension (W x D x H)

257mm x 590mm x 570mm

Product weight

86kg(189.2lb)

Display (LED/LCD)

LED – line mode (green), bypass / battery mode (yellow), fault (red)
LCD – input / output voltage and frequency, on-line mode, backup mode, battery capacity, load level

Communication interface

Standard – RS-232; *Optional – USB B-type and/or SNMP

Audible noise

< 60dBA (1m from surface)

Ambient temperature

+0 °C to +40 °C

Storage temperature

-20 °C to +50 °C

Humidity

0-95%, non-condensing
