Supermicro SuperServer 6018R-MTR/BULK

Socket Type

Dual LGA 2011-3

Processor

1x Intel® Xeon® processor E5-2600v3 3.70GHz 45MB

Intel® Xeon® processor E5-2600 v3 family (up to 135W TDP **)

Dual Socket R3 (LGA 2011)

Chipset

• Intel® C612 Express chipset

• Memory Capacity

• 8x 288-pin DDR4 DIMM sockets
• Up to 512GB ECC LRDIMM, 256GB ECC RDIMM
• 2133/1866/1600MHz ECC DDR4 SDRAM 72-bit
• RDIMM: 32GB, 16GB, 8GB, 4GB
• LRDIMM: 64GB, 32GB

• Drive Bays

• 10x Hot-swap 2.5″ Drive Bays: 10x SATA3 ports by default; optional 8x SAS3 ports
• 10x 2.5″ Hot-swap drive bays

• RAID Supports

• I-SATA 4 & I-SATA 5 support SATA DOM
• SATA3 (6Gbps); RAID 0, 1, 5, 10
• Support for Intelligent Platform Management Interface v.2.0
• IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • ASPEED AST2400 BM

• Graphics

• ASPEED AST2400 BMC​​​​​

• Expansion Slots

• 1x PCI-E 3.0 x8 Full-height Half-length

• Input / Onput

• 4x SATA3 (6Gbps) ports
• 2x RJ45 Gigabit Ethernet LAN ports
• 1x RJ45 Dedicated IPMI LAN port
• 2x USB 3.0 ports (rear)
• 2x USB 2.0 ports (rear)
• 1x Type A
• 1x VGA port
• 2x Fast UART 16550 port / 1 Header
• 2x SuperDOM (Disk on Module) ports

• Network Controller

• Support for Intelligent Platform Management Interface v.2.0
• IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
• ASPEED AST2400 BMC

• PSU

• 400W Redundant Power Supplies
  400W (1+1) Redundant SuperCompact Short-depth AC-DC Gold-level power supply with PMBus and I2C

• Chassis Type

• 1U Rackmount

• OS

• Support:

  Microsoft® Windows Server® 2012
  Microsoft Windows Server 2012 Essentials
  Microsoft Windows Server 2008 R2 SP1, x64 (includes
  Hyper-V® v2)
  Novell® SUSE® Linux Enterprise Server
  Red Hat® Enterprise Linux®
  Virtualizations options:
  Citrix® XenServer®
  VMware® vSphere® ESX™ and ESXi™
  Red Hat Enterprise Virtualization®

• Dimensions
