UPS Powercom MRT-1000-2U

MODEL

MRT-1000

MRT-2000

MRT-3000

CAPACITY

1000VA

2000VA

3000VA

1000W

2000W

3000W

INPUT

Nominal voltage

208V / 220V / 230V / 240V

Voltage range

120V to 300V
(120~140V under 25% load, 140~160V under 50% load, 160~190V under 75% load, 190~276V under 100% load)

Frequency

50Hz to 65Hz auto sensing

Phase

Single phase

Power factor

≧0.99 @ Nominal Voltage (100% Load)

OUTPUT

Voltage

208V / 220V / 230V / 240V ±2% (selectable output voltage)

Frequency

50Hz / 60Hz ±0.25Hz

Waveform

Pure sine wave

Phase

Single phase

Harmonic distortion

≦ 2.5% THD at non-linear load

≦ 2 % THD at linear load

High efficiency mode

>95%

Cress Factor

3 : 1

Connections

Standard IEC C13 ; C19 (C19 only for MAS-3000)          Customized outlets can be discussed.

PROTECTION

Overload protection

UPS automatic power off if overload exceeds 105% to 120% of nominal at 30 seconds; 121% to 150% for 10 seconds

Short circuit protection

         UPS output cut off immediately or protected by input fuse or circuit breaker

Tele-communication

RJ45

Surge protection

 230V (IEEE C61000-4-5 level 3)

BATTARY

Type

Sealed, maintenance-free lead acid battery

Typical recharge time

4 hours to 90%

Battery quantity

12V 7Ah x3

12V 7Ah x6

12V 9Ah x6

Managent

Self-test, adjustable battery transfer pointes and alarm settings

Cold start (DC start)

                                                                         Yes

Backup time (100% load)

2 – 4 minutes

Protection

Battery low cut-off without draining any current

GENERAL

Dimension (W x D x H)

428mm x 425mm x 84mm

                                428mmx635mmx84mm

Product weight

12.4kg

23.2kg

27.6kg

Display (LED/LCD)

LED – line mode (green), bypass / battery mode (yellow), fault (red)

LCD – input / output voltage and frequency, on-line mode, backup mode, battery capacity, load level

Communication interface

Standard – RS-232,USB B-type *Optional – SNMP

Audible noise

            < 45dBA (1m from surface)

Ambient temperature

+0 °C to +40 °C

Storage temperature

 – 20 °C to +50 °C

Altitude

2000 meters max

Humidity

0-95%, non-condensing
