Single-Port 10/100/1000Mbps Ultra PoE Injector (60 Watts) POE-171

Interface

    2-Port RJ-45 interface

    – 1-Port Data + Power output

    – 1-Port Data input

    1 DC 52~56V input power socket

Power over Ethernet

    Ultra Power over Ethernet End-Span/Mid-Span PSE

    IEEE 802.3at/af PoE standard compliant

    Compatible with All IEEE 802.3at/af powered devices

    Supports 56VDC, 60-watt PoE power output at maximum

    Auto-detection of PoE IEEE 802.3at/af equipment and device for possible damage by incorrect installation

    Automatic detection and protection of non–standard Ethernet terminals

    Remote power feeding up to 100 meters

Hardware

    Compact size metal case

    LED indicators for power LED and PoE In-use LED

Standard Compliance

    IEEE 802.3 10Base-T

    IEEE 802.3u 100Base-TX

    IEEE 802.3ab 1000Base-T

    IEEE 802.3at High Power over Ethernet

    IEEE 802.3af Power over Ethernet

    FCC Part 15 Class A, CE
