Máy chủ CASE SUPERMICRO 846BE16-R9 (SuperServer 4U)

Name: Máy chủ CASE SUPERMICRO 846BE16-R9 (SuperServer 4U) - Máy chủ Hà Nội
SKU: SSR4U007
Price: 39000000 VND
Availability: InStock

Mã: SSR4U007 Bình luận: 0 | Lượt xem: 869

4U chassis support for max. motherboard size – 13.68″ x 13″ E-ATX, 12″ x 10″ ATX and 9.6″ x 9.6″ Micro-ATX Processor Support Dual and Single Intel® and AMD processors Dimensions Height 7″ (178 mm) Width 17.2″ (437 mm) Depth 26″ (660 mm) Net Weight 55 lbs (24.95 kg) Gross Weight […]

Bảo hành: 24 tháng

Còn hàng

Máy chủ CASE SUPERMICRO 846BE16-R9 (SuperServer 4U)

Mô tả

4U chassis support for max. motherboard size – 13.68″ x 13″ E-ATX, 12″ x 10″ ATX and 9.6″ x 9.6″ Micro-ATX


Processor Support

Dual and Single Intel® and AMD processors


Dimensions

Height	7″ (178 mm)
Width	17.2″ (437 mm)
Depth	26″ (660 mm)
Net Weight	55 lbs (24.95 kg)
Gross Weight	75 lbs (34.02 kg)
Packaging (W x H x L)	34.3″ (871 mm) x 26.5″ (673 mm) x 13.5″ (343 mm)
Available Color	Black


Expansion Slots

7 full-height & full-length expansion slot(s)


Drive Bays

24 x 3.5″ hot-swap drive bay


Peripheral Drives

Optional 1 x 3.5″ internal fixed drive bay Optional 2 x 2.5″ internal fixed drive bay Optional 2 x 2.5″ hot-swap drive bay


Front Panel

Buttons	Power On/Off button System Reset Button
LEDs	2 Network Activity LEDs Fan Fail/System Over Heat LED HDD activity LED Power Status LED Unit Identification (UID) LED

Systems Cooling

Fans	3 x 8cm hot-swap redundant PWM cooling fan(s) 2 x 8cm hot-swap exhaust fan(s) & air shroud


System Monitoring

Chassis intrusion switch


Operating Environment (System)

Operating Temperature Range	5°C – 35°C (41°F – 95°F)
Non-Operating Temperature Range	-40°C – 70°C (-40°F – 158°F)
Operating Relative Humidity Range	8% – 90% (non-condensing)
Non-Operating Relative Humidity Range	5% – 95% (non-condensing)


Power Supply
1U 920W Redundant Platinum Level Power Supply
Power Efficiency	94%
Total Output Power and Input	920W with Input 100 – 240Vac
AC Input Frequency	50-60Hz
Dimensions (L x W x H)	336 x 76 x 40 mm
Output Type	Backplanes (gold finger)
-12V	Max: NAA
+12V	Max: 75A / Min: 0.5A (100Vac – 240Vac)
+5Vsb	Max: 4A / Min: 0A
+12Vsb	Max: NAA
Power Distributor	PDB-PT846-2824
Certification	Platinum Certified
