Product Specifications
|
Board Order Code |
S2400SC2 |
|---|---|
| Essentials | |
|
Limited 3-year warranty |
Yes |
|
Extended warranty available for purchase |
Yes |
|
On-site repair (select countries) |
Yes, when integrated into an Intel® Server Chassis |
|
Board form factor |
SSI CEB 12″ x 10.5″ |
|
Chassis form factor |
Rack or pedestal |
|
Max CPU Configuration |
2 |
|
Socket |
Socket B2 |
|
Integrated systems available |
Yes |
|
Integrated BMC with IPMI |
IPMI 2.0 |
|
Rack-friendly board |
Yes |
|
Embedded options available |
No |
|
Included Items |
(1)General Purpose Intel® Server Board S2400SC2, On Select SKUs: (1) I/O Shield, (4) SATA cables, (1) DVD contains Intel® Multi-Server Manager Software and Intel Deployment Assistant, (1) Quick Start User Guide, (1) Attention Doc |
|
Memory Specifications |
|
|
Max. memory size (dependent on memory type) |
128 GB |
|
Memory types |
DDR3/LV DDR3 ECC UDIMM 1066/1333, RDIMM/LV RDIMM 1066/1333/1600 (no LRDIMM, QRDIMM) |
|
# of memory channels |
6 |
|
Max. memory bandwidth |
614.4 GB/s |
|
# of DIMMs |
8 |
|
ECC memory supported |
Yes |
|
Graphics Specifications |
|
|
Integrated graphics |
Yes |
|
Graphics output |
D-sub |
|
Discrete graphics |
Supported |
|
Expansion Options |
|
|
PCI support |
Supported |
|
PCI Express* revision |
3 |
|
PCIe* x4 Gen3 |
1 |
|
PCIe x8 Gen3 |
1 |
|
PCIe x16 Gen3 |
1 |
|
PCIe x4 Gen 2.x |
1 |
|
I/0 Specifications |
|
|
USB revision |
USB 2.0 |
|
# of USB ports |
4 |
|
USB 2.0 configuration (back + internal) |
6 |
|
# of SATA ports |
6 |
|
RAID configuration |
SW RAID 0/1/10/5 (LSI + RSTE) |
|
# of serial ports |
2 |
|
# of LAN ports |
2 |
|
Integrated LAN |
2x 1 GbE |
|
Embedded USB (eUSB) solid-state drive option |
Yes |
|
Integrated SAS ports |
0 |
|
Integrated InfiniBand* |
No |
|
Advanced Technologies |
|
|
Intel® Trusted Execution Technology |
Yes |
|
Intel® AES New Instructions |
Yes |
|
Intel® Remote Management Module support |
Yes |
|
Intel® Intelligent Power Node Manager |
Yes |
|
Intel® Trusted Platform Module (Intel® TPM) |
Yes |
|
Intel® TPM version |
Intel® TPM version 2.0 |
|
Intel® Quiet System Technology |
No |
|
Intel® Matrix Storage Technology |
Yes |
|
Intel® Fast Memory Access |
Yes |
|
Intel® Flex Memory Technology access |
Yes |
|
Intel® I/O Acceleration Technology |
Yes |
|
Intel® Server Board Technology Innovations |
|
|
Intel® Advanced Management Technology |
Full capabilities |
|
Intel® Efficient Power Technology |
Full capabilities |
|
Intel® Quiet Thermal Technology |
Full capabilities |
|
Compatible Products Lists |
|
|
Compatible Chassis |
Intel® Server Chassis P4304XXSHDN Intel® Server Chassis P4304XXSHEN Intel® Server Chassis P4208XXMHDR Intel® Server Chassis P4216XXMHEN Intel® Server Chassis P4308XXMHGR Intel® Server Chassis P4308XXMHEN Intel® Server Chassis P4308XXMFEN Intel® Server Chassis P4216XXMHJC Intel® Server Chassis P4304XXSHDR Intel® Server Chassis P4304XXSFDR Intel® Server Chassis P4304XXSFDN Intel® Server Chassis P4304XXSFEN Intel® Server Chassis P4216XXMHGC Intel® Server Chassis P4208XXMHGC Intel® Server Chassis P4216XXMHGR Intel® Server Chassis P4308XXMHGC Intel® Server Chassis P4308XXMFGN |
| Compatible Systems |
Intel® Server System P4308SC2MHGC Intel® Server System P4304SC2SFEN Intel® Server System P4304SC2SHDR |
|
Compatible RAID |
Intel® RAID Controller SRCSASRB Intel® RAID Controller SRCSASJV Intel® RAID Controller SRCSASBB8I Intel® RAID Controller SRCSASLS4I Intel® RAID Controller RS2BL080 Intel® RAID Controller RS2BL040 Intel® RAID Controller RS2PI008 Intel® RAID Controller RS2WC080 Intel® RAID Controller RS2WC040 Intel® RAID Controller RS2PI008DE Intel® RAID Controller RS2SG244 Intel® RAID Controller RT3WB080 Intel® RAID Controller RS2VB080 Intel® RAID Controller RS25DB080 Intel® RAID Controller RS25GB008 Intel® RAID Expander RES2CV240 Intel® RAID C600 Upgrade Key RKSATA4R5 Intel® RAID C600 Upgrade Key RKSATA8 Intel® RAID C600 Upgrade Key RKSATA8R5 Intel® RAID C600 Upgrade Key RKSAS4 Intel® RAID C600 Upgrade Key RKSAS4R5 Intel® RAID C600 Upgrade Key RKSAS8 Intel® RAID C600 Upgrade Key RKSAS8R5 Intel® RAID Expander RES2CV360 Intel® RAID Controller RS25AB080 |
|
Compatible processor |
Intel® Xeon® Processor E5-2450L (20M Cache, 1.80 GHz, 8.00 GT/s Intel® QPI) Intel® Xeon® Processor E5-2450 (20M Cache, 2.10 GHz, 8.00 GT/s Intel® QPI) Intel® Xeon® Processor E5-2440 (15M Cache, 2.40 GHz, 7.20 GT/s Intel® QPI) Intel® Xeon® Processor E5-2430L (15M Cache, 2.00 GHz, 7.20 GT/s Intel® QPI) Intel® Xeon® Processor E5-2407 (10M Cache, 2.20 GHz, 6.40 GT/s Intel® QPI) Intel® Xeon® Processor E5-2403 (10M Cache, 1.80 GHz, 6.40 GT/s Intel® QPI) Intel® Xeon® Processor E5-2430 (15M Cache, 2.20 GHz, 7.20 GT/s Intel® QPI) Intel® Xeon® Processor E5-2420 (15M Cache, 1.90 GHz, 7.20 GT/s Intel® QPI) Intel® Xeon® Processor E5-2449L (20M Cache, 1.20 GHz, 8.00 GT/s Intel® QPI) Intel® Xeon® Processor E5-2470 (20M Cache, 2.30 GHz, 8.00 GT/s Intel® QPI) |
|
Compatible software |
VMware vSphere 5 Essentials VMW5ESS* VMware vSphere 5 Standard VMW5STD* VMware vSphere 5 Enterprise VMW5ENT* VMware vSphere 5 Enterprise Plus VMW5ENTPLUS* VMware vSphere 5 vCenter Standard VMW5VCSTD* Intel® Server Continuity Suite System Manager Intel® Server Continuity Suite System Manager Intel® Server Continuity Suite Data Protection Manager Intel® Server Continuity Suite Data Protection Manager Intel® Server Continuity Suite Advanced Data Protection Manager Intel® Server Continuity Suite Advanced Data Protection Manager Intel® Server Continuity Suite 2 Year Maintenance Subscription Intel® Server Continuity Suite 2 Year Maintenance Subscription |
|
Compatible spares and accessories |
Dual Processor System Extended Warranty Dual Processor Board Extended Warranty Remote Management Module AXXRMM4LITE Remote Management Module AXXRMM4 Dual Processor System On-Site Repair Air Duct Spare FSCUPSAD (For Intel® Server Board S2400SC in P4000S) Air Duct Spare FSCUPMAD (For Intel® Server Board S2400SC in P4000M) Trusted Platform Module AXXTPME5 Intel RAID Expander RES2SV240NC Accessory Heat Sink AXXCA90X902UHS optimized for Intel® P4000 Chassis Accessory Fan Kit ASCUPSFLFANKIT for Intel® Server Board S2400SC in P4000S Chassis for full length HBA IO shield AXX2IOS |
|
Compatible network interface card |
Intel® Ethernet Server Adapter X520-SR1 Intel® Ethernet Server Adapter X520-SR2 Intel® Ethernet Server Adapter X520-DA2 Intel® Ethernet Server Adapter X520-LR1 Intel® Gigabit ET2 Quad Port Server Adapter Intel® Gigabit EF Dual Port Server Adapter Intel® Gigabit ET Dual Port Server Adapter Intel® PRO/1000 PT Quad Port Server Adapter Intel® Ethernet Server Adapter X520-T2 Intel® Ethernet Server Adapter I350-T2 Intel® Ethernet Server Adapter I350-T4 Intel® Ethernet Server Adapter I350-F2 Intel® Ethernet Server Adapter I350-F4 |
|
Tested Component Lists |
|
|
Tested memory list |
S2400SC2 |
|
Tested hard drive list |
S2400SC2 |
|
Tested operating system list |
S2400SC2 |
