| Form factor/height | 2U |
| Processor (max) |
|
| Cache (max) | 30 MB per processor |
| Memory (max) |
|
| Media bays | Up to two 5.25-inch half-high bays, support for DVD-ROM or multiburner, half-high SATA DVD-ROM standard in standard models |
| Disk bays (total) | Sixteen 2.5-inch or six 3.5-inch HDDs or thirty-two 1.8-inch SSDs |
| RAID support | M5110e,Integrated 6 Gbps or new optional 12 Gbps* hardware RAID-0, -1, -10 with optional RAID-5, -50, -6, -60. |
| Power supply (std/max) |
|
| Hot-swap components | Power supplies, fan modules and hard disk drives |
| Network interface |
|
| Expansion slots | 4 – 6 PCIe ports or 4 PCI-X (CTO) or 2 double-width PCIe (for GPU) |
| USB ports | 2 front/4 back/2 internal |
| Maximum internal storage | Up to 25.6 TB (2.5-inch model) or 24 TB (3.5-inch model) SAS/SATA |
| Energy efficiency | 80 PLUS Platinum and ENERGY STAR (model dependent) Compliance |
| Systems management | IMM2 with optional FoD remote presence, Predictive Failure Analysis, Diagnostic LEDs, light path diagnostics panel, Automatic Server Restart, IBM Systems Director Active Energy Manager |
| Operating systems supported | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere |
