| Cache | 1 GB cache per controller with 2 GB upgrade (battery-backed) |
| Drive interfacee | 1x 6Gb SAS 2 Port Daughter Card |
| Host interface | Three options: Four 6 Gbps SAS ports Four 8 Gbps FC ports and Two 6 Gbps SAS ports Four 1 Gbps iSCSI ports and Two 6 Gbps SAS ports |
| Storage | 12 bay (3.5′) Hot swap, Supports 6 Gbps SAS 3.5″ Drives:300 GB 15k rpm, 450 GB 15k rpm, 600 GB 15k rpm, 1 TB 7.2k rpm Nearline, 2 TB 7.2k rpm Nearline, 600 GB 15k rpm SED |
| RAID controller | Raid ( 0, 1, 3, 5, 6, 10) Dual Active, hot-swappable controllers |
| Maximum drives supported | Up to 96 drives—high performance SAS drives, nearline SAS drives, and SED SAS drives EXP3512 (2U 12 3.5-in drives) and EXP3524 (2U 24 2.5-in drive) enclosures, which can be intermixed behind a DS3500 enclosure |
| power supplies | Dual redundant, hot-swappable |
| Rack support | 2U, 19-inch, industry-standard rack |
| Management software | IBM System Storage DS® Storage Manager |
| SAN support | Supported IBM FC switches and directors, and IP switches |
IBM SYSTEM STORAGE DS3512 EXPRESS SINGLE CONTROLLER
Mã: IBM DS3512 SINGLE
Bình luận: 0 | Lượt xem: 1339
Cache 1 GB cache per controller with 2 GB upgrade (battery-backed) Drive interfacee 1x 6Gb SAS 2 Port Daughter Card Host interface Three options:Four 6 Gbps SAS portsFour 8 Gbps FC ports and Two 6 Gbps SAS portsFour 1 Gbps iSCSI ports and Two 6 Gbps SAS ports Storage 12 bay (3.5′) Hot swap, Supports […]
62.250.000 ₫
Bảo hành: 36 tháng
Còn hàng
IBM SYSTEM STORAGE DS3512 EXPRESS SINGLE CONTROLLER
