IBM Storwize V3700 3.5-inch Storage Expansion Unit (6099LEU)

Mã: V3700 3.5" Bình luận: 0 | Lượt xem: 1313

One Storwize V3700 LFF expansion unit with two power supplies with cooling modules and with two expansion canisters

12 LFF drive bays in the expansion unit; up to 9x expansion units

Two 2.8 m, 10 A/100 – 250 V, C13 to IEC 320-C14 Rack Power Cables (AC-powered models only)

Two DC power cables (DC-powered models only)

Bảo hành: 36 tháng

Còn hàng

One Storwize V3700 LFF expansion unit with two power supplies with cooling modules and with two expansion canisters

12 LFF drive bays in the expansion unit; up to 9x expansion units

Two 2.8 m, 10 A/100 – 250 V, C13 to IEC 320-C14 Rack Power Cables (AC-powered models only)

Two DC power cables (DC-powered models only)

IBM Storwize V3700 3.5-inch Storage Expansion Unit (6099LEU)

Mô tả

or	Storwize V3700 Controller Unit: 2U rack mount Storwize V3700 Expansion Unit: 2U rack mount
Controller unit configuration	Dual controller (known as node canister) configuration.
RAID levels	RAID 0, 1, 5, 6, and 10; Distributed RAID 5 and 6 (Distributed RAID is supported with the Spectrum Virtualize Software for V3700 version 7.6 onwards, which requires 4 GB to 8 GB cache upgrades).
Controller cache	8 GB per system (4 GB per node canister) upgradeable to 16 GB (8 GB per node canister). Battery-backed cache protection.
Drive bays	Up to 240 SFF drive bays per storage system: 24 SFF drive bays in the controller unit 24 SFF drive bays in the expansion unit; up to 9x expansion units Intermix of SFF and LFF units is supported.
Drive technology	SAS and NL SAS HDDs and SAS SSDs. Intermix of HDDs and SSDs is supported.
Drive connectivity	Dual-ported 6 Gb SAS drive attachment infrastructure. Controller unit with two node canisters (ports per one node canister): 24x 6 Gb SAS internal drive ports (SFF enclosure) 1x 6 Gb SAS x4 (Mini-SAS HD SFF-8644) expansion port for the attachment of the expansion units Expansion unit with two expansion canisters (ports per one expansion canister): 24x 6 Gb SAS internal drive ports (SFF enclosure) 2x 6 Gb SAS x4 (Mini-SAS HD SFF-8644) expansion ports for the daisy chained attachment of the expansion units
Storage capacity	Up to 960 TB (120x 8 TB NL SAS HDDs)
Host connectivity	Standard ports (per controller unit with two node canisters): 6x 6 Gb SAS host ports (Mini-SAS HD, SFF-8644) (3 ports per node canister) 4x 1 Gb iSCSI host ports (UTP, RJ-45) (2 ports per node canister) Optional additional ports on host interface cards (per controller unit with two node canisters): 8x 6 Gb SAS host ports (Mini-SAS HD, SFF-8644) (4 ports per node canister) 8x 1 Gb iSCSI host ports (UTP, RJ-45) (4 ports per node canister) 4x 10 Gb iSCSI or FCoE SFP+ host ports (SW fiber optics, LC) (2 ports per node canister) 8x 8 Gb FC SFP host ports (SW or LW fiber optics, LC) (4 ports per node canister)
Host operating systems	Microsoft Windows Server 2008 R2, 2012 and 2012 R2; Red Hat Enterprise Linux (RHEL) 5, 6, and 7; SUSE Linux Enterprise Server (SLES) 10, 11, and 12; VMware vSphere 5.0, 5.1, 5.5, and 6.0.
Power Supply	Two redundant hot-swap 735 W AC
Management interfaces	2x 1 GbE ports (UTP, RJ-45) in a primary/redundant configuration. Web-based GUI; SSH CLI; SMI-S; SNMP and email notifications.
Form Fact	Rack (2U), Rail Kit
Warranty	Three-year customer-replaceable unit and onsite warranty with 9×5 next business day terms.
