Ubiquiti UniFi AP-AC Outdoor Key Features
Frequency – 2.4 GHz, 5 GHz
2.4 GHz Throughput – 450 Mbps
5 GHz Throughput – 1300 Mbps
Range – 183 m
802.11 a/b/g/n/ac
Dual band 3×3 MIMO
1750 Mbps aggregate throughput
Product Model Number: UAP-AC-OUTDOOR
Power over Ethernet (PoE)
Includes Power over Ethernet (PoE) functionality. Each UniFi model includes a Power over Ethernet adapter, and it can also be powered by the Ubiquiti TOUGHSwitch PoE (sold separately).The UniFi AP-AC Outdoor is compatible with an 802.3at compliant switch.
Ubiquiti UniFi AP-AC Outdoor – Technical Specifications
General
Dimensions 340 x 180 x 65 mm
Weight 1.55 kg (with Wall Mount) 2 kg (with Pole Mount)
Networking Interface (2) 10/100/1000 Ethernet Ports
Buttons: Reset
2.4 GHz Antenna – Integrated 5 dBi Omni (Supports 3×3 MIMO with Spatial
Diversity)
5 GHz Antenna- Integrated 5 dBi Omni (Supports 3×3 MIMO with Spatial Diversity)
Wi-Fi Standards 802.11 a/b/g/n/ac
Power Method: Passive Power over Ethernet (48V), 802.3at Supported (Supported Voltage Range: 39 to 57VDC)
Power Supply: 48V, 0.5A PoE Gigabit Adapter (Included)
Maximum Power Consumption: 22 W
2.4 GHz and 5 GHz Maximum TX Power – 28 dBm
BSSID Up to Four Per Radio
Power Save Supported
Wireless Security WEP, WPA-PSK, WPA-TKIP, WPA2 AES, 802.11i
Certifications CE, FCC, IC
Mounting Wall and Pole (Kits Included)
Operating Temperature -30 to 60 °C
Operating Humidity 5 – 80% Non-Condensing
Advanced Traffic Management
VLAN 802.1Q
Advanced QoS Per-User Rate Limiting
Guest Traffic Isolation Supported
WMM Voice, Video, Best Effort, and Background
Concurrent Clients 200+
Supported Data Rates (Mbps)
802.11a – 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n – 6.5 Mbps to 450 Mbps (MCS0 – MCS23, HT 20/40)
802.11ac – 6.5 Mbps to 1300 Mbps (MCS0 – MCS9 NSS1/2/3, VHT 20/40/80)
802.11b – 1, 2, 5.5, 11 Mbps
802.11g – 6, 9, 12, 18, 24, 36, 48, 54 Mbps
