Switch Cisco SF95D-08 8 port

Ports

SF95D-08: 8 RJ-45 connectors for 10BASE-T/100BASE-TX

Automatic medium dependent interface (MDI) and MDI crossover (MDI-X); auto-negotiated port for connecting 10-, 100-, 1000-Mbps devices

Standards

IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, 802.1p priority, Energy Efficient Ethernet

Cabling type

Category 5e or better

LED indicators

System/PWR, link/activity, 100M*, cable diagnostics, loop detection (*if present)

Power supply

SF95D-08: DC 12V, 500mA

Physical dimensions (W x D x H)

SF95D-08: 160x30x90 mm

Weight

SF95D-08: 0.83 lb. (0.38 kg)

Switching capacity

SF95D-08: 1.6 Gbps

Forwarding capacity

Forwarding rate in million packets per second (mpps) (based on 64-byte packets): SF95D-08: 1.4. mpps

Compliance/certifications

UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B
