| Hardware Specifications | |
| CPU | |
| CPU Model | Annapurna Labs Alpine AL-212 |
| CPU Architecture | 32-bit |
| CPU Frequency | Dual Core 1.4 GHz |
| Floating Point | |
| Hardware Encryption Engine | |
| Memory | |
| System Memory | 1 GB DDR3 |
| Storage | |
| Drive Bay(s) | 4 |
| Compatible Drive Type (See all supported drives) |
|
| Maximum Internal Raw Capacity | 32 TB (8 TB HDD x 4) (Capacity may vary by RAID types) |
| Maximum Single Volume Size | 16 TB |
| Hot Swappable Drive | |
| External Ports | |
| USB 3.0 Port | 3 |
| File System | |
| Internal Drives | EXT4 |
| External Drives |
|
| Appearance | |
| Size (Height x Width x Depth) | 165 mm x 203 mm x 233.2 mm |
| Weight | 2.04 kg |
| Others | |
| RJ-45 1GbE LAN Port | 2 (with Link Aggregation / Failover support) |
| Wake on LAN/WAN | |
| System Fan | 92 mm x 92 mm x 2 pcs |
| Fan Speed Mode |
|
| Wireless Support (dongle) | |
| Power Recovery | |
| Noise Level* | 20.2 dB(A) |
| Scheduled Power On/Off | |
| Power Supply Unit / Adapter | 90W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption* | 31.96 W (Access) 10.14 W (HDD Hibernation) |
| British Thermal Unit | 109.13 BTU/hr (Access) 34.62 BTU/hr (HDD Hibernation) |
| Environment Temperature | |
| Operating Temperature | 5°C to 40°C (40°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certification |
|
| Warranty | 2 Years |
| Notes |
|
| DSM Specifications ( See more ) | |
| Storage Management | |
| Maximum Internal Volume Number | 256 |
| Maximum iSCSI Target Number | 10 |
| Maximum iSCSI LUN | 10 |
| Supported RAID Type |
|
| RAID Migration |
|
| Volume Expansion with Larger HDDs |
|
| Volume Expansion by Adding a HDD |
|
| Global Hot Spare Supported RAID Type |
|
| File Sharing Capacity | |
| Maximum User Accounts | 2048 |
| Maximum Groups | 256 |
| Maximum Shared Folder | 256 |
| Maximum Shared Folder Sync Tasks | 4 |
| Maximum Concurrent CIFS/AFP/FTP Connections | 256 |
| Windows Access Control List (ACL) Integration | |
| NFS Kerberos Authentication | |
| Log Center | |
| Syslog Events per Second | 400 |
| Add-on Packages (See more) | |
| Antivirus Essential | |
| Audio Station | |
| Cloud Station | |
| Maximum Concurrent File Transfers | 256 |
| Cloud Sync | |
| Directory Server | |
| DNS Server | |
| Download Station | |
| Maximum Concurrent Download Tasks | 50 |
| Glacier Backup | |
| HiDrive Backup | |
| iTunes Server | |
| Java Manager | |
| Mail Server | |
| Mail Station | |
| Media Server | |
| DLNA Certification | |
| Note Station | |
| Photo Station | |
| RADIUS Server | |
| Surveillance Station | |
| Maximum IP cam (Licenses required) | 25 (including 2 Free License) (See All Supported IP Cameras) |
| Total FPS (H.264)* | 750 FPS @ 720p (1280×720) 200 FPS @ 1080p (1920×1080) 150 FPS @ 3M (2048×1536) 100 FPS @ 5M (2591×1944) |
| Total FPS (MJPEG)* | 250 FPS @ 720p (1280×720) 100 FPS @ 1080p (1920×1080) 60 FPS @ 3M (2048×1536) 40 FPS @ 5M (2591×1944) |
| Video Station | |
| Video Transcoding | Group 1 – Type 2 (See more) |
| VPN Server | |
| Maximum Connections | 15 |
| Notes | Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera. |
| Environment & Packaging | |
| Environment | RoHS Compliant |
| Packaging Content |
|
| Optional Accessories |
|
