Workstation Dell Precision 3640 (W-1270/16GB RAM/2TB HDD) (42PT3640D11)

10th Generation Intel® Core™ i9-10900K, 20 MB Cache, 10 Core, 3.7 GHz to 5.3 GHz – DDR4 2933

10th Generation Intel® Core™ i9-10900, 20 MB Cache, 10 Core, 2.8 GHz to 5.2 GHz – DDR4 2933

10th Generation Intel® Core™ i7-10700K, 16 MB Cache, 8 Core, 3.8 GHz to 5.0 GHz – DDR4 2933

10th Generation Intel® Core™ i7-10700, 16 MB Cache, 8 Core, 2.9 GHz to 4.7 GHz – DDR4 2933

10th Generation Intel® Core™ i5-10600K, 12 MB Cache, 6 Core, 4.1 GHz to 4.8 GHz – DDR4 2666

10th Generation Intel® Core™ i5-10600, 12 MB Cache, 6 Core, 3.3 GHz to 4.8 GHz – DDR4 2666

10th Generation Intel® Core™ i5-10500, 12 MB Cache, 6 Core, 3.1 GHz to 4.5 GHz – DDR4 2666

10th Generation Intel® Core™ i3-10100, 6 MB Cache, 4 Core, 3.6 GHz to 4.3 GHz – DDR4 2666

10th Generation Intel® Xeon® W-1290P, 20 MB Cache, 10 Core, 3.7 GHz to 5.3 GHz – DDR4 2666

10th Generation Intel® Xeon® W-1290, 20 MB Cache, 10 Core, 3.2 GHz to 5.2 GHz – DDR4 2666

10th Generation Intel® Xeon® W-1270P, 16 MB Cache, 8 Core, 3.8 GHz to 5.1 GHz, DDR4 2666

10th Generation Intel® Xeon® W-1270, 16 MB Cache, 8 Core, 3.4 GHz to 4.9 GHz – DDR4 2666

10th Generation Intel® Xeon® W-1250P, 12 MB Cache, 6 Core, 4.1 GHz to 4.8 GHz – DDR4 2666

10th Generation Intel® Xeon® W-1250, 12 MB Cache, 6 Core, 3.3 GHz to 4.7 GHz – DDR4 2666

Windows® 10 Professional (64 bit)

Windows® 10 Pro for Workstations (64 bit) w/ Intel Xeon® processors

Windows® 10 Home (64 bit)

Red Hat® Enterprise Linux® 8.2 (coming soon)

Ubuntu® 18.04 SP1

NeoKylin 7.0 (China only)

4 Dimm Slots; Up to 128GB 2666MHz or 2933MHz (2933MHz requires Intel Core i7 or above)

Non-ECC & ECC DDR4 Memory

One PCI Express® x16 Gen 3 slot supporting graphics card up to 300W

(Total power available for discrete graphics cards).

(Some cards are available in Dual Config as well)

High End cards:

NVIDIA Quadro® RTX5000

AMD Radeon Pro™ W5700

Mid-range 3D cards: NVIDIA Quadro® RTX4000

NVIDIA Quadro® P2200

AMD Radeon Pro™ W5500

Entry 3D cards:(all single or dual)

NVIDIA Quadro® P1000

AMD Radeon Pro™ WX3200

NVIDIA Quadro® P620

NVIDIA Quadro® P400

Support for up to (2) M.2 PCIe SSD on motherboard slot and up to (3) 3.5” SATA® or (4) 2.5” SATA®.

Support for Intel® Ready Mode™ technology

Support for up to (1) additional PCIe SSD

On Dell Precision Ultra-Speed drive (x8) with active cooling

M.2 PCIe NVMe™ SSD up to (2) 2TB (max 4TB) on M/B

Up to (1) 2TB on Dell Precision Ultra-Speed drive

SATA® 2.5” 7200 RPM

Up to (4) 2TB 7200 RPM

SATA® 3.5”

Up to (3) 8TB 7200 RPM

Self Encrypting Drives

512GB M.2 NVMe™ SSD Class 40 SED

256 GB M.2 NVMe™ Class 40 SED

1 TB M.2 NVMe™ Class 40 SED

500 GB 2.5-inch OPAL SATA SED FIPS HDD

Internal Speaker; Optional Dell 2.0 stereo speaker systems available and Dell sound bar for select

Flat-panel displays

Integrated: Intel® Ethernet Connection I219-LM 10/100/1000

Optional: Intel 10/100/1000 PCIe Gigabit Networking card

Aquantia® AQtion™ AQN-108 5/2.5 GbE NIC Adapter

Optional: WLAN on M.2 2230 port with up to Wi-Fi® 6 (802.11ax) wireless module and Bluetooth® 5

Support for up to (1) additional PCIe SSD on Dell Precision Ultra-Speed drive (x8) with active cooling

Thunderbolt™ 3 PCIe Card

Serial and Parallel Port PCIe Card (Full Height)

USB 3.2 Type CTM Gen 2 PCIe Card (Full Height)

Powered USB 3.2 PCIe Card

Smart Card Reader (CAC/PIV) with pre-boot authentication support

Front: Front of the chassis has 2 I/O offerings – Standard and Advanced

With following differences in USB and SD card reader.

(Availability depends on chassis selection and region)

Standard offering

2x USB 2.0 Type A

1x USB 3.2 Type A Gen1 (5Gbps), with PowerShare

1x USB 3.2 Type CTM Gen2 (10Gbps), with PowerShare

No SD card reader

Advanced offering

1x USB 3.2 Type A Gen1 (5Gbps)

1x USB 3.2 Type A Gen2 (10Gbps)

1x USB 3.2 Type A Gen2 (10Gbps), with PowerShare

1x USB 3.2 Type CTM Gen2 (10Gbps)

, with PowerShare With SD card reader Other Front ports

1x 3.5mm headphone jack with microphone Rear Starting from top, going left to right

2x DisplayPortTM

2x PS2 (Legacy for keyboard and mouse)

1x Optional Port (VGA, HDMI 2.0, DP++ 1.2, Type CTM w/DP-Alt mode)

2x USB 2.0 Type A (with SmartPower)

1x RJ45 Network Connector 2x USB 3.2 Type A Gen2 (10Gbps)

2x USB 3.2 Type A Gen1 (5Gbps)

1x Audio Line out

HxWxD: 13.19” x 6.95” x 13.58” (33.5cm x 17.7cm x 34.5cm), Min weight: 9.358Kg

Bays: (3) internal 3.5” bays – supports (3) 3.5” or (4) 2.5” storage drives

Slots: 2x M.2 2280 slots for PCIe NVMe™ SSDs, 1x M.2 2230 WLAN slot, 1x PCIe x16 Gen3 (full height),

1x PCI (full height), 1x PCIe x4 Gen3 (open ended, full height)

Power Supply:

300W 85% efficient PSU (80PLUS Bronze Certified);

300W 90% efficient PSU (80PLUS Gold Certified Certified)Energy Star compliant;

460W 90% efficient PSU (80PLUS Gold Certified Certified) Energy Star compliant;

550W 90% efficient PSU (80PLUS Gold Certified) Energy Star compliant;

1000W 90% efficient PSU (80 PLUS Gold Certified) Energy Star compliant

(300W Bronze and 1000W Gold PSU not available in certain regions.)

Optional:

1 optical drive: DVD-ROM; DVD+/-RW, Blu RayTM Writer

(Note: optical drive not available with Smart Card Reader (CAC/PIV))

SD Card Reader (Note: SD card reader is available in Advanced front I/O offering only.

Availability for a chassis may differ across regions.)

Trusted Platform Module TPM 2.0, Dell Data Guardian, Dell Endpoint Security Suite Enterprise,

Dell HW Crypto Accelerator, Microsoft Windows Bitlocker, Local HDD data wipe via BIOS (“Secure Erase”),

Encryption – SED HDD (Opal FIPS), Chassis lock slot support, Chassis Intrusion Switch, D-Pedigree

(Secure Supply Chain Functionality), Setup/BIOS Password,

Optional Smart Card keyboards,

Intel® Trusted Execution Technology,

Intel® Identity Protection Technology, Dell Secure Works, BIOS support optional Computrace,

Intel Software Guard extensions

ENERGY STAR® configurations available including 80 PLUS® Bronze and Gold power supplies

(Bronze not available in the Americas);

EPEAT Silver registered. (see epeat.net for specific registration rating/status by country);

China CECP; GS Mark.

For a complete listing of declarations & certifications, see Dell’s regulatory & compliance homepage at dell.com/regulatory_compliance

3-Year Limited Hardware Warranty and 3-year NBD On-Site Service after Remote Diagnosis

Optional: Dell ProSupport is designed to rapidly respond to your business’s needs, help protect your investment

And sensitive data and provide enhanced proactive support services to help reduce risk and complexity

Within your IT environment
