Tech Specs & Customization
Processor
Up to two 3rd Generation Intel® Xeon® Scalable processors with up to 40 cores per processor
Operating System
Canonical® Ubuntu® Server LTS
Citrix® Hypervisor®
Microsoft® Windows Server® with Hyper-V
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®/vSAN
Chipset
Intel® C620 series chipset with optional Intel®QuickAssist Technology
Memoryi
DIMM Speed
Up to 3200 MT/s
Memory Type
RDIMM
LRDIMM
Intel® Persistent Memory 200 series (BPS)
Memory Module Slots
32 DDR4 DIMM slots
Maximum RAM
RDIMM max 2 TB
LRDIMM max 4 TB
Intel® Persistent Memory 200 series (BPS) max 8 TB
Storage
Front Bays
Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 7.6 TB per drive
Up to 6 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 7.6 TB per drive
Storage Controllers
Internal Controllers
PERC H755 MX, PERC H745P MX, HBA350i MX
External Controllers
PERC H745P MX, HBA330 MMZ
Software RAID
S150
Internal Boot
Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2 x M.2 SSDs 240 GB or 480 GB
Internal Dual SD Module or USB
Security
TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Digitally Signed Firmware
Chassis Intrusion Alert Secure Boot
Secure Erase
Silicon Root of Trust
System Lockdown (requires iDRAC Enterprise or Datacenter)
Management
Embedded / At-the-Server
iDRAC9
iDRAC Direct
iDRAC Service Module
Consoles
OpenManage Enterprise
OpenManage Power Manager plugin
OpenManage SupportAssist plugin
OpenManage Update Manager plugin
OpenManage Enterprise Modular Edition
Mobility
OpenManage Mobile
Tools
RACADM CLI
iDRAC RESTful API with Redfish IPMI
System Update Utility Update Catalogs
OpenManage Integrations
BMC® Truesight
Microsoft® System Center RedHat® Ansible Modules
VMware® vCenter and vRealize Operations Manager
OpenManage Connections
IBM Tivoli® Netcool/OMNIbus
IBM Tivoli® Network Manager IP Edition
Micro Focus® Operations Manager
Nagios® Core
Nagios® XI
Ports
Front Ports
1 x iDRAC Direct port (Micro-AB USB)
1 x USB 3.0
Internal Ports
1 x USB 3.0
Networking Options
MX7000 chassis Fabric options: up to 2 pairs redundant general-purpose switch or pass-through modular bays (Fabrics A and B); redundant pair of storage specific switch bays (Fabric C)
Up to 25 Gb CNA/NIC per port for Mezz A/B, 32 Gb Fibre Channel, 12 Gbps SAS for Mezz C
Slots
One x16 PCIe Gen4 slot for Mezz A – connected to processor 1
One x16 PCIe Gen4 slot for Mezz B – connected to processor 2
One x16 PCIe Gen4 slot for mini-Mezz card – connected to processor 2
One x16 PCIe Gen4 slot for PERC – connected to processor 1
Two x8 PCIe Gen4 connectors for NVMe drive – connected to processor 1 One x8 PCIe Gen4 connector for NVMe drive – connected to processor 2
Two x4 PCIe Gen3 slots for BOSS M.2 HW RAID card – connected to Platform Controller Hub (PCH)
Chassis
MX7000
Form Factor
Up to 8 independent hot-swappable, 1U single-width compute sled in a MX7000 chassis
Dimensions & Weight
Height
42.15 mm (1.65 inches)
Width
250.2 mm (9.85 inches)
Depth
594.99 mm (23.42 inches)
Weight
8.3 kg (18.29 lb)
Recommended Support
Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region.
