| Feature | Technical Specifications | |
| Processor | Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor | |
| Memory | • 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s• Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max• Supports registered ECC DDR4 DIMMs only | |
| Storage controllers | • Internal controllers: PERC H745, HBA355I, S150, H345, H755, H755N• Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB• Boot Optimized Storage Subsystem (BOSS-S1) HW RAID 2 x M.2 SSDs 240 GB or 480 GB• External PERC (RAID): PERC H840, HBA355E | |
| Drive Bays | Front bays:• Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB• Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB• Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB• Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.84 TB Rear bays:• Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB• Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB | |
| Power Supplies | • 700 W Titanium HLAC/240 mixed mode• 800 W Platinum AC/240 mixed mode• 1100 W Titanium AC/240 mixed mode• 1100 W DC -48 – -60 V• 1400 W Platinum AC/240 mixed mode• 1800 W Titanium HLAC/240 mixed mode• 2400 W Platinum AC/240 mixed mode• 2800 W Titanium HLAC/240 mixed mode | |
| Cooling Options | Air cooling, optional processor liquid cooling | |
| Fans | • Standard fan/High performance SLVR fan/High performance GOLD fan• Up to six hot plug fans | |
| Dimensions | • Height – 86.8 mm (3.41 inches)• Width – 482 mm (18.97 inches)• Depth – 758.3 mm (29.85 inches) – without bezel772.14 mm (30.39 inches) – with bezel | |
| Form Factor | 2U rack server | |
| Embedded Management | • iDRAC9• iDRAC Service Module• iDRAC Direct• Quick Sync 2 wireless module | |
| Bezel | Optional LCD bezel or security bezel | |
| OpenManage Software | • OpenManage Enterprise• OpenManage Power Manager plugin• OpenManage SupportAssist plugin• OpenManage Update Manager plugin | |
| Mobility | OpenManage Mobile | |
| Integrations and Connections | OpenManage Integrations • BMC Truesight• Microsoft System Center• Red Hat Ansible Modules• VMware vCenter and vRealize Operations Manager | OpenManage Connections• IBM Tivoli Netcool/OMNIbus• IBM Tivoli Network Manager IP Edition• Micro Focus Operations Manager• Nagios Core• Nagios XI |
| Security | • Cryptographically signed firmware• Secure Boot• Secure Erase• Silicon Root of Trust• System Lockdown (requires iDRAC9 Enterprise or Datacenter)• TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ | |
| Embedded NIC | 2 x 1 GbE LOM | |
| Network Options | 1 x OCP 3.0 (x8 PCIe lanes) | |
| GPU Options | Up to two double-width 300 W, or three single-width 150 W, or six single-width 75 W accelerators | |
| Ports | Front Ports• 1 x Dedicated iDRAC Direct micro-USB• 1 x USB 2.0• 1 x VGA | Rear Ports• 1 x USB 2.0• 1 x Serial (optional)• 1 x USB 3.0• 2 x RJ-45• 1 x VGA (optional for liquid cooling configuration) |
| Internal Ports• 1 x USB 3.0 | ||
| PCIe | Up to 8 x PCIe Gen4 slots (up to 6 x16) with support for SNAP I/O modules |
