IBM X3550 M5 1U Rackmount System LGA-2011-3

Socket Type

Dual Socket R3 2011-3

Processor

Intel Xeon E5-2600 v3 series

Chipset

Intel C612

Memory Capacity

Up to 24 DIMM sockets (12 DIMMs per processor). RDIMMs and LRDIMMs (Load Reduced DIMMs) are supported.. Memory types cannot be intermixed. Memory speed up to 2133 MHz.

Drive Bays

Up to 12x 2.5″ hot-swap SAS/SATA HDDs, or up to 8x 2.5″ Simple Swap SATA HDDs, or up to 4x 3.5″ hot-swap SAS/SATA HDDs, or up to 4x 3.5″ Simple Swap SATA HDDs.

RAID Supports

Onboard 6 Gb SATA: no RAID support

12 Gb SAS/SATA RAID: RAID 0, 1, 10 with M1215 or M5210. Optional upgrade to RAID 5, 50 is available for M1215. Optional upgrade to RAID 5, 50 is available for M5210 (zero-cache; 1 GB non-backed cache; 1 GB, 2 GB, or 4 GB flash-backed cache). Optional upgrade to RAID 6, 60 is available for M5210 with memory cache upgrades. Optional SSD Caching and Performance Accelerator feature upgrades are available.

12 Gb SAS/SATA non-RAID: N2215 HBA

Graphics

Matrox G200eR2 with 16 MB memory integrated into the IMM2. Maximum resolution is 1600×1200 at 75 Hz with 16 M colors.?????

Expansion Slots

Up to four slots, depending on the riser cards installed. The slots are as follows:

Slot 1: PCIe 3.0 x16 or ML2; low profile, half-length (not present if the HDD Rear Kit is installed)

Slot 2: PCIe 3.0 x16 or PCIe 3.0 x8; low profile or full-height, half-length (PCIe 3.0 x16 slot requires the second processor to be installed) (not present if the HDD Rear Kit is installed)

Slot 3: PCIe 3.0 x16 or PCIe 3.0 x8; low profile, half-length

Slot 4: PCIe 3.0 x8 (dedicated for an internal RAID controller)

Input / Onput

Front: 1x USB 3.0, 1x USB 2.0 (8x 2.5″ drive bay models) or 2x USB 2.0 (4x 3.5″ and 10x 2.5″ drive bay models), and 1x DB-15 video.

Rear: 2x USB 3.0, 1x USB 2.0, 1x DB-15 video, 1x RJ-45 systems management, 4x RJ-45 GbE network ports. Optional 1x DB-9 serial port.

Internal: 1x USB port (for embedded hypervisor).

Network Controller

Four integrated RJ-45 Gigabit Ethernet 1000BASE-T ports (BCM5719); optional Mezzanine LOM (ML2) slot for dual-port 10 GbE cards with SFP+ or RJ-45 connectors or quad-port GbE cards with RJ-45 connectors.

PSU

Up to two redundant hot-swap 550 W, 750 W, or 900 W High Efficiency Platinum AC power supplies, or 750 W High Efficiency Titanium AC power supplies.

Chassis Type

1U rackmount

OS

Support Microsoft Windows Server 2012 R2, 2012, and 2008 R2, Red Hat Enterprise Linux 6 and 7, SUSE Linux Enterprise Server 11, VMware vSphere (ESXi) 5.1 and 5.5.

Dimensions
