Form factor/height | Tower/4U (rack-mountable) |
Processor (max) |
Up to two 12-core Intel Xeon Processor E5-2600 v2 product family 1 x Intel® Xeon® 4-Core Processor E5-2609v2, 2.5GHz 10M 6.4GT/s QPI |
Cache (max) | Up to 30 MB per processor |
Memory (max) |
Up to 768 GB, 24 slots (UDIMM/RDIMM/LRDIMM) 1 x 4GB PC3-10600 CL9 ECC DDR3 1600MHz LP RDIMM |
Media bays | One optional optical bay for 2.5-inch model |
Disk bays (total) | Eight 2.5-inch hot-swap or eight 3.5-inch hot-swap bays standard, up to thirty-two 2.5-inch hot-swap bays via optional upgrade kit, or eight 3.5-inch simple-swap bays via configure to order |
RAID support |
M1115 SAS/SATA Integrated 6 Gbps or new optional 12 Gbps hardware RAID-0, -1, -10 with optional RAID-5, -50, -6, -60 upgrades |
Power supply (std/max) |
1/2 hot-swap redundant 550 W/750 W/900 W, 80 PLUS® Platinum 1 x IBM 750W Redundant Power Supply Unit |
Hot-swap components | Power supply and hard disk drives |
Network interface |
Intel I350AM4 quad-port Gigabit Ethernet |
Expansion slots | Up to eight PCIe expansion slots; Six PCIe slots standard, plus two additional PCIe slots when the second processor is populated. An optional PCI-X slot is available via an interposer conversion kit. |
Maximum internal storage | Up to 51.2 TB of 2.5-inch hot-swap drives (HDD upgrade options required) or 48 TB of 3.5-inch hot-swap or simple-swap SAS/SATA HDDs |
Energy efficiency | Fixed power supply compliant with 80 PLUS Bronze/ Redundant power supply compliant with 80 PLUS Gold |
Systems management | IMM2 with optional FoD remote presence, Predictive Failure Analysis, Diagnostic LEDs, light path diagnostics panel, Automatic Server Restart, IBM Systems Director Active Energy Manager |
Operating systems supported | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere |
