CASE SUPERMICRO 846TQ-R900B

Thông số kỹ thuật chi tiết CASE SUPERMICRO 846TQ-R900B

• CSE-846TQ-R900B:

  SuperChassis 846TQ-R900B

• Form Factor:

  4U chassis support for max. motherboard size - 13.68" x 13" E-ATX, 12" x 10" ATX and 9.6" x 9.6" Micro-ATX

• Processor Support:

  Dual and Single Intel® and AMD processors

• Height :

  7" (178 mm)

• Width:

  17.2" (437 mm)

• Depth:

  26" (660 mm)

• Net Weight :

  55 lbs (24.95 kg)

• Gross Weight :

  75 lbs (34.02 kg)

• Packaging (W x H x L) :

  34.3" (871 mm) x 26.5" (673 mm) x 13.5" (343 mm)

• Available Color :

  Black

• Expansion Slots:

  7 full-height & full-length expansion slot(s)

• Drive Bays:

  24 x 3.5" hot-swap drive bay
  Optional 1x Fixed Internal Hard Drive Bay and 1x DVD-ROM Drive or Floppy Drive

• Backplane:

  24-port 4U TQ (W/ AMI 9072 enclosure management) backplane, support up to 24x 3.5-inch SAS/SATA HDD/SSD

• Peripheral Drives:

  Optional 2 x 2.5" internal fixed drive bay

• Front Panel:

  Buttons:
  - Power On/Off button
  - System Reset Button
  LEDs:
  - 2 Network Activity LEDs
  - Fan Fail/System Over Heat LED
  - HDD activity LED
  - Power Status LED
  - Unit Identification (UID) LED

• Systems Cooling:

  Fans:
  - 3 x 8cm hot-swap redundant PWM cooling fan(s)
  - 2 x 8cm hot-swap exhaust fan(s) & air shroud

• System Monitoring:

  Chassis intrusion switch

• Power Distributor:

  PDB-PT846-8824
  O/P: 12V/75A
  +5V Max: 50A
  +3.3V Max: 24A
  -12V Max: 0.6A

• Power Supply Safety / EMC:

  BSMI
  CCC
  CE/EMC
  FCC class A
  TUV/CB
  UL/CB
  UL/CUL
