Hardware Specifications |
|
|
PoE |
802.3af PoE PD, PD Class 3 |
|
Interface |
Wireless IEEE 802.11b/g/n |
|
LAN: 1x 10/100BASE-TX, auto-MDI/MDIX, 802.3af PoE compliant |
|
|
Antenna |
Built-in 2T2R, 3dbi antenna |
|
LED |
Power/position LED (Allowing LED to turn off via software control) |
|
Button |
Reset button (Press over 5 seconds to reset the device to factory default) |
|
Wireless Interface Specifications |
|
|
Standard |
IEEE 802.11b/g/n 2.4GHz |
|
Antenna Structure |
802.11n: 2T2R MIMO |
|
Modulation |
Transmission/emission type: DSSS/OFDM |
|
Data modulation type: OFDM: BPSK, QPSK, 16-QAM, 64-QAM, DBPSK, DQPSK, CCK |
|
|
Frequency Range |
Americav-FCC: 2.412~2.462GHz |
|
Europe-ETSI: 2.412~2.472GHz |
|
|
Operating Channels |
America-FCC: 1~11 |
|
Europe-ETSI: 1~13 |
|
|
Channel Width |
802.11n: 20/40MHz |
|
Transmission Distance |
802.11n: up to 70m |
|
802.11g: up to 30m |
|
|
The estimated transmission distance is based on the theory |
|
|
The actual distance will vary in different environments |
|
|
Max. RF Power |
802.11n: 17 ± 2dBm |
|
802.11g: 17 ± 2dBm |
|
|
802.11b: 18 ± 2dBm |
|
|
Data Rate |
IEEE 802.11b: 1/2/5.5/11Mbps |
|
IEEE 802.11g: 6/9/12/18/24/36/48/54Mbps |
|
|
IEEE 802.11n: 300 Mbps in 40MHz mode/150Mbps in 20MHz mode |
|
|
Software Features |
|
|
Operation Mode |
Standalone AP |
|
Managed AP |
|
|
Wireless Mode |
AP (Multiple-SSIDs) |
|
Client |
|
|
Repeater (WDS+AP) |
|
|
Universal Repeater (AP+Client) |
|
|
WDS PtP Bridge |
|
|
WDS PtMP Bridge |
|
|
Wireless Encryption |
WEP (64/128 bit) encryption security |
|
WPA/WPA2 (TKIP/AES) |
|
|
WPA-PSK/WPA2-PSK (TKIP/AES) |
|
|
802.1x RADIUS Authentication |
|
|
Wireless Security |
Wireless MAC address filtering (up to 20 entries) |
|
Supports WPS (Wi-Fi Protected Setup) |
|
|
SSID broadcast and hide |
|
|
Wireless Advanced |
Supports WMM (Wi-Fi Multimedia) for better data transmission of video or on-line demand |
|
Supports wireless schedule |
|
|
Multiple SSIDs: up to 5 |
|
|
Wireless Isolation: Enables it to isolate each connected wireless client of a BSSID from communicating with each other |
|
|
IAPP (Inter Access Point Protocol): 802.11f wireless roaming |
|
|
Provides wireless statistics, max. associated station number |
|
|
Max. Clients |
Wired: 253 |
|
2.4GHz Wireless: 32 |
|
|
LAN |
Built-in DHCP server supporting static IP address distribution |
|
Supports static IP and dynamic IP |
|
|
Supports UPnP |
|
|
Supports 802.1d Spanning Tree |
|
|
Max. WDS Peers |
8 |
|
IEEE Standards |
IEEE 802.11n (2T2R, up to 300Mbps) |
|
IEEE 802.11g |
|
|
IEEE 802.11b |
|
|
IEEE 802.11i |
|
|
IEEE 802.3 10BASE-T |
|
|
IEEE 802.3u 100BASE-TX |
|
|
IEEE 802.3x flow control |
|
|
Power Consumption |
≤4.5W (max.) |
|
Other Protocols and Standards |
CSMA/CA, CSMA/CD, TCP/IP, DHCP, ICMP, SNTP |
|
Power Requirements |
802.3af/at PoE, 48-56V DC input, 0.35A (max.) 5VDC input, 1A (max.) |
|
Mounting |
Ceiling Mount, Wall Mount |
|
Material |
Plastic |
|
Dimensions (Φ x H) |
144 x 33 mm |
|
Weight |
128 ±5g |
